Specifications

• Technical

  ---

  Enclosure Color

  Black

  Active Area

  13.55" x 7.62" / 344.2 mm x 193.5 mm

  Number of Colors

  266,144

  Brightness (typical)

  LCD Panel: 220 nits
  PCAP: 187 nits

  Aspect Ratio

  16:9

  Resolution

  1366 x 768 @ 60Hz

  Number of Touches

  Multi Touch (Up to 10)

  Diagonal Size

  15.6'' diagonal, Active matrix TFT LCD (LED)

  Monitor Width

  15.2" / 386.2 mm

  Monitor Height

  14.54" / 369.3 mm

  Monitor Depth

  8.71" / 221.2 mm

  Viewing Angle

  Horizontal: 45°/45° or 90° total / Vertical: 15°/35° or 50° total

  Contrast Ratio

  400:1

  Response Time-total (typical)

  10 msec

  Power Supply

  External 24VDC universal-type power supply brick
  AC input voltage: 100-240 VAC
  Input frequency: 50-60 Hz
  Maximum output power: 180W

  Power Consumption (Typical)

  24W

  Operating Temperature

  0°C to 35°C / 32°F to 95°F

  Storage Temperature

  -20°C to 60°C / -4°F to 140°F

  Humidity

  Operating: 20% to 80%
  Storage: 5% to 95% (38.7℃ max wet bulb temperature)

  Other Features

  Serviceable internal components.
  Kensington lock.

  MTBF

  50,000 hours demonstrated

  Warranty

  3-year
